High-end Dual-end Small Wire Crimping Machine

JCW-CST05

Wire Cross section: 0.03 - 2 mm² ( AWG32 -14 )

Cutting length: 22 - 99999 mm

Front side stripping: 0.2 - 8 mm

Rear side stripping: 0.1 - 10 mm

Crimping force: 20 KN ( 2 tons )

3600 pcs/h by 50mm wire length [ CRIMP ONE END ]

Control: Panasonic PLC

Inquire Now

Mitsubishi Servo Motor, Panasonic PLC

JCW-CST05 Fully Automatic Servo Motorized Wire Crimping Machine

Single wire dual-end stripping to crimping of wires with small cross-sections

High-end crimping machine

The JCW-CST05 is a high-end fully-auto wire stripping and crimping machine. The machine allows prefeeding, cutting, stripping, and crimping of wires in the cross-section range from 0.1 mm² to 2 mm², crimping force is 2 tons ( 20 KN ). Synchronous wire pre-feeder keeps proper wire tension. All parameters such as wire data and crimp data can be saved and retrieved for future use.

High-quality processing and simple operation

The JCW-CST05 is a fully automatic wire processing machine for the toughest requirements. The machine integrates high-quality components, Nidec servo motors, Panasonic PLC, a highly rigid transmission structure, high-speed control system. Production parameters are entered with the 7" WEINVIEW touch screen monitor via the intuitive user interface to reduce training time and minimize entry errors. The JCW-CST05 offers vivid detection functions, wire lack detection, wire knot detection, stripping detection, crimping detection, air pressure detection, etc.

Various peripherals

- Crimping force monitoring ( CFM )

- Wire prefeeder for keeping proper wire tension

- Conveyor belt for stacking finished wire

Model	JCW-CST05 Automatic Servo Motorized Wire Crimping Machine
Function	Wire pre-feeder, Single / Dual-end strip, Single / Dual-end crimp, Cut depth, Pull-off length, Crimp position
Conductor cross-section	0.03 - 2 mm² ( AWG 32 - 14 )
Stripping length	Front Side: 0.2 - 8 mm
Stripping length	Rear Side: 0.1 - 10 mm
Cutting length	22 - 99999 mm
Crimping force	20 KN ( 2.0 tons )
Cutting depth adjustment	0.01mm, max 3.50mm
Production rate	3600 pcs/h [ cutting length 50mm, crimp one side ]
Rated power	2200 ~ 2500W
Power supply	AC 110 - 220V ± 10%, 50 / 60 Hz
Air supply	0.5 - 0.7 MPa [ Clean and dry air ]
Weight	460 KG
Dimensions	L 1400 x W 1000 x H 1800mm
Accessory device	Synchronous wire pre-feeder, paper winder
Optional peripheral	Wire pre-feeder, CFM, wire stacker
Detection	Wire lack, Wire jam, Stripping, Crimping, Air pressure
CE-Conformity	Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility.
