Process both outer sheath & inner wire
Double stripping in one work cycle
Specific blades match different cables
Powerful cylinders, lower power consumption
Adjustable stripping length
Robust & compact design
JCW-S03M
Process both outer sheath & inner wire
Double stripping in one work cycle
Specific blades match different cables
Powerful cylinders, lower power consumption
Adjustable stripping length
Robust & compact design
Low-price Multicore Cable Stripper
Model | JCW-S03M Pneumatic Multicore Cable Stripping Machine |
Raw material | PVC, Teflon, Silicone, Low halogen, Fiberglass, etc |
Cable O.D | Φ 3 - 10 mm |
Inner wire O.D | Φ 1 - 2 mm |
Outer stripping length | 15 - 90 mm |
Inner stripping length | 1.5 - 15 mm |
Power supply | AC 110 - 220 V ± 10%, 50 / 60 Hz |
Air supply | 0.4 - 0.7 MPa ( clean and dry air ) |
Dimensions | L 720 x W 340 x H 250 mm |
Weight | 30 KG |
CE-Conformity | Complies with CE equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility. |
